Universal Aluminium Radiator - 55mm Core

Aluminium Radiator with either a 42mm, 55mm or 70mm core. This will give you the best cooling needed for your engine depending on application - either road only, road and track or track only.

Outlet sides are selected as an option, please select this when deciding which radiator configuration you require.

The dimensions of the radiator are 465 x 310 as seen on picture 2

The cooling fan can be mounted to the radiator on either the forward or rearward facing sides.  This radiator comes with the fan mounting bosses 415mm x 180mm (w x h) on both sides of the radiator.

Engine Choices and Pipe Layouts

Suzuki Hayabusa : Top Right, Bottom Right - 25mm Outlets

Yamaha R1 : Top Left, Bottom Left - 32mm Outlets

Mazda MX-5 : Top Left, Bottom Left - 32mm Outlets

Please Note : These products are made to order due to the varying combinations of pipe outlets and positions, lead time is approx 14 - 21 working days.
